Flange Type Gearboxes

Foot Mounted Type Gearboxes

Interested with this service. Want to work with us for your Next Project?

Get a Quote

A20

i
Ratio		 n2
rpm		 Mn2
Nm		 Pn1
kW		 Rn1
N		 Rn2
N
5.49 255 60 1.7 600 950
6.46 217 60 1.4 600 1040
7.75 181 60 1.2 600 1150
8.57 163 60 1.1 600 1210
9.92 141 65 0.86 600 1220
11.67 120 65 0.86 600 1340
14.00 100 65 0.72 600 1470
15.48 90 65 0.65 600 1540
18.01 78 80 0.68 600 1490
21.19 66 80 0.58 600 1620
25.43 55 80 0.48 600 1780
28.13 50 80 0.44 600 1880
31.71 44 80 0.39 600 1940
37.31 38 80 0.33 600 2100
44.77 31 80 0.28 600 2290
49.52 28.3 80 0.25 600 2400

A25

i
Ratio		 n2
rpm		 Mn2
Nm		 Pn1
kW		 Rn1
N		 Rn2
N
5.02 279 120 3.7 350 760
5.92 236 120 3.1 450 800
6.47 216 120 2.9 560 860
7.88 178 120 2.3 760 1000
8.93 157 130 2.2 440 950
10.53 133 130 1.9 630 1080
11.51 122 130 1.7 720 1150
14.01 100 130 1.4 830 1310
16.42 85 160 1.5 380 1150
19.35 72 160 1.3 580 1320
21.16 66 160 1.2 670 1400
25.75 54 160 1.0 830 1600
31.27 45 160 0.8 510 1720
36.86 38 160 0.7 690 1910
40.29 35 160 0.6 780 2020
49.29 29 160 0.5 830 2260

A30

i
Ratio		 n2
rpm		 Mn2
Nm		 Pn1
kW		 Rn1
N		 Rn2
N
5.11 274 230 6.9 550 1350
6.22 225 230 5.7 850 1500
6.93 202 230 5.1 1000 1600
7.51 186 230 4.7 700 1600
7.78 180 230 4.6 000 1750
9.14 153 260 4.4 920 1650
10.18 138 260 3.9 1000 1800
11.43 122 260 3.5 1000 2000
12.62 111 260 3.2 770 2000
15.37 91 260 2.6 1000 2300
17.11 82 260 2.3 1000 2500
19.21 73 260 2.1 1000 2600
24.19 58 320 2.0 490 2500
29.45 48 320 1.7 1000 2800
32.80 43 320 1.5 1000 3050
36.82 38 320 1.3 1000 3300

A35

i
Ratio		 n2
rpm		 Mn2
Nm		 Pn1
kW		 Rn1
N		 Rn2
N
5.11 274 340 10.3 900 4500
6.22 225 340 8.4 1050 4950
6.96 202 340 7.6 1140 5200
7.51 186 340 7.0 1050 5280
7.78 180 340 6.7 1200 5480
9.14 153 400 6.7 1100 5460
10.18 138 400 6.1 1150 5470
11.43 122 400 5.4 1150 6050
1262 111 400 4.9 1050 6160
15.37 91 400 4.0 1150 6750
17.11 82 400 3.6 1150 7070
19.21 73 400 3.2 1150 7200
24.19 58 480 3.1 1150 7200
29.45 48 480 2.5 1150 7200
32.80 43 480 2.3 1150 7200
36.82 38 180 2.0 1150 7200
